Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
13
Explanation of machine data and setting data
1.1 Data in the list
System
Specifies the control system for which the data with the entered values applies.
By default, the entered values apply for both the SINUMERIK 808D ADVANCED Turning and
SINUEMRIK 808D ADVANCED Milling.
If no "default" entry exists, the data only apply for the control variants specified:
Default values
Specifies a default value fort he machine data. If the default values for the channels are
different, they are separated with a comma ",".
Range of values (minimum/maximum value)
Specifies the limits for the entered values. If no range of value is specified, the data type
determines the input limits, and the field is marked with a dash "-".
Protection
The SINUMERIK 808D ADVANCED provides a concept of access levels for enabling data
areas. The access levels correspond with protection levels 0 to 7 (0: the highest level; 7: the
lowest level). You can view such information from the table shown as below:
For the function areas listed below, the inpu
t and mo
dification of data depends on the
protection level you have set:
• Tool offsets
• Work offsets
FLOAT DWORD
Real value: ±7.43 x 10
-37
to 3.37 x 10
38
UBYTE Integer value: 0 to 255
LONG Integer value: 4,294,967,296 to 4,294,967,295
Designator Meaning
808d-te62 SINUMERIK 808D ADVANCED Turning
808d-me62 SINUMERIK 808D ADVANCED Milling
Protection level Access level Default password Target group
0 Siemens - Reserved for Siemens
1 Manufacturer SUNRISE OEMs
2Reserved
3 Customer CUSTOMER End users
4 - Key-operated switch setting 3 End users
5 - Key-operated switch setting 2 End users
6 - Key-operated switch setting 1 End users
7 No password - -
