Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
151
Machine data
2.3 Channel-specific machine data
Description: Group assignment of predefined auxiliary functions.
The predefined groups cannot be changed for indices 0, 1, 2, 3, 4, 22, 23,
24.
Description: The address codes of the predefined auxiliary functions are fix.
This setting cannot be changed!
Description: Address extension for predefined auxiliary functions:
This setting can be changed only for indices 5 to 17 and 21!
Description: Value of predefined auxiliary functions.
This setting cannot be changed!
22040 AUXFU_PREDEF_GROUP C04 H2
- Predefined auxiliary function groups DWORD PowerOn
-
- 301 1, 1, 1, 1, 1, 1, 2,
2, 2, 2, 2, 4, 4, 4,
4, 4, 4, 3, 1, 1, 1...
0 168 2/2
22050 AUXFU_PREDEF_TYPE C04 H2
- Predefined auxiliary function type STRING PowerOn
-
- 301 "M", "M", "M", "M",
"M", "M", "M", "M",
"M", "M", "M", "M",
"M"...
- - 2/2
22060 AUXFU_PREDEF_EXTENSION C04 H2
- Predefined auxiliary function extension DWORD PowerOn
-
- 301 0, 0, 0, 0, 0, 0, 1,
1, 1, 1, 1, 1, 1, 1,
1, 1, 1, 1, 0, 0, 0...
-1 99 2/2
22070 AUXFU_PREDEF_VALUE C04 H2
- Predefined auxiliary function value DWORD PowerOn
-
- 301 0, 1, 2, 17, 30, 6, 3,
4, 5, 19, 70, 40, 41,
42, 43, 44, 45, -1...
- - 2/2
