Machine data
2.3 Channel-specific machine data
Parameter Manual
152
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
Specification of the output behavior of the predefined auxiliary functions.
Bit 0 = 1Acknowledgment "normal" after an OB1 cycle
Bit 1 = 1Acknowledgment "quick" with OB40
Bit 2 = 1No predefined auxiliary function
Bit 3 = 1No output to the PLC
Bit 4 = 1Spindle reaction after acknowledgment by the PLC
Bit 5 = 1Output before the motion
Bit 6 = 1Output during the motion
Bit 7 = 1Output at block end
Bit 8 = 1No output after block search types 1, 2, 4
Bit 9 = 1 Collection during block search type 5 (SERUPRO)
Bit 10 = 1No output during block search type 5 (SERUPRO)
Bit 11 = 1Cross-channel auxiliary function (SERUPRO)
Bit 12 = 1Output via synchronized action
Bit 13 = 1 Implicit auxiliary function
Bit 14 = 1 Active M01
Bit 15 = 1 No output during running-in test
Bit 16 = 1 Nibbling off
Bit 17 = 1 Nibbling on
Bit 18 = 1 Nibbling
Description: Acknowledgment time for auxiliary functions in ms.
See MD22010 $MC_AUXFU_PREDEF_TYPE[n] (auxiliary function type)
22080 AUXFU_PREDEF_SPEC C04 H2,K1
- Output specification DWORD PowerOn
-
- 301 0x81, 0x81, 0x81,
0x81, 0x81, 0x8021...
0x0, 0x0, 0x0,
0x0, 0x0,
0x8000,
0x8000...
0x77FFF,
0x77FFF,
0x77FFF,
0x77FFF...
1/1
22090 AUXFU_PREDEF_SIM_TIME C04 H2,S1
- Acknowledgment time DWORD PowerOn
-
- 64 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0...
0 0x7FFFFFF 2/2
