Siemens SINUMERIK 808D ADVANCED User Manual

Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
153
Machine data
2.3 Channel-specific machine data
Description: This machine data defines an additional, predefined M function, which behaves
in the same way as M0. The value of the machine data corresponds to the num-
ber of the auxiliary M function.
Predefined M numbers, such as M0, M1, M2, M3, etc., are not allowed.
Restriction:
See MD10715 $MN_M_NO_FCT_CYCLE
Related to:
MD10714 $MN_M_NO_FCT_EOP,
MD10715 $MN_M_NO_FCT_CYCLE,
MD20094 $MC_SPIND_RIGID_TAPPING_M_NR,
MD22254 $MC_AUXFU_ASSOC_M0_VALUE
MD10814 $MN_EXTERN_M_NO_MAC_CYCLE,
MD10804 $MN_EXTERN_M_NO_SET_INT
MD10806 $MN_EXTERN_M_NO_DISABLE_INT,
MD10800 $MN_EXTERN_CHAN_SYNC_M_NO_MIN,
MD10802 $MN_EXTERN_CHAN_SYNC_M_NO_MAX
MD20095 $MC_EXTERN_RIGID_TAPPING_M_NR
MD26008 $MC_NIBBLE_PUNCH_CODE
Description: This machine data defines an additional, predefined M function, which behaves
in the same way as M1. The value of the machine data corresponds to the num-
ber of the auxiliary M function.
Predefined M numbers, such as M0, M1, M2, M3, etc., are not allowed.
Restriction:
See MD10715 $MN_M_NO_FCT_CYCLE
Related to:
MD10714 $MN_M_NO_FCT_EOP,
MD10715 $MN_M_NO_FCT_CYCLE,
MD20094 $MC_SPIND_RIGID_TAPPING_M_NR,
MD22254 $MC_AUXFU_ASSOC_M0_VALUE
MD10814 $MN_EXTERN_M_NO_MAC_CYCLE,
MD10804 $MN_EXTERN_M_NO_SET_INT
MD10806 $MN_EXTERN_M_NO_DISABLE_INT,
MD10800 $MN_EXTERN_CHAN_SYNC_M_NO_MIN,
MD10802 $MN_EXTERN_CHAN_SYNC_M_NO_MAX
MD20095 $MC_EXTERN_RIGID_TAPPING_M_NR
MD26008 $MC_NIBBLE_PUNCH_CODE
22254 AUXFU_ASSOC_M0_VALUE C01, C03, C10 H2,K1
- Additional M function to stop a program DWORD PowerOn
-
- - -1, -1, -1, -1, -1, -1, -1,
-1...
- - 2/2
22256 AUXFU_ASSOC_M1_VALUE C01, C03, C10 H2
- Additional M function for conditional stop DWORD PowerOn
-
- - -1, -1, -1, -1, -1, -1, -1,
-1...
- - 2/2
