Machine data
2.3 Channel-specific machine data
Parameter Manual
160
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
The machine data is intended for diagnostics.
The recording of the diagnostic data does not start until the event
(TRACE_STARTTRACE_EVENT) has occurred at the trace point
(TRACE_STARTTRACE_TRACEPOINT) and in the correct step
(TRACE_STARTTRACE_STEP)!
The machine data is additionally activated using the Cancel alarm key.
Description: The machine data is only intended for diagnostic use.
See TRACE_STARTTRACE_EVENT
For TRACE_STARTTRACE_EVENT BLOCK_CHANGE the string TRACE_STARTTRACE_STEP is
interpreted as a file name and block number!
For BSEVENTTYPE_SETALARM the string is interpreted as an alarm number.
The machine data can be additionally activated using the Cancel alarm key.
Description: The machine data is only intended for diagnostics.
The recording of the diagnostic data ends when the event
(TRACE_STOPTRACE_EVENT) has occurred at the trace point
(TRACE_STOPTRACE_TRACEPOINT) and in the correct step (TRACE_STOPTRACE_STEP)!
After reaching the stop condition, the previously recorded diagnostic data is
stored in a file "NCSCTRyy.MPF" or for NCU-LINK in "NCxxTRyy.MPF" in the MPF
directory.
The machine data is additionally activated using the Cancel alarm key.
Description: The machine data is only intended for diagnostics.
The machine data can be additionally activated using the Cancel alarm key.
22700 TRACE_STARTTRACE_EVENT EXP, C06 -
- Diagnostic data rec. starts with event
TRACE_STARTTRACE_EVENT.
STRING PowerOn
NBUP
- - ... - - 1/1
22702 TRACE_STARTTRACE_STEP EXP, C06 -
- Conditions for start of trace recording STRING PowerOn
NBUP
- 2 , , , , , , , , , ... - - 1/1
22704 TRACE_STOPTRACE_EVENT EXP, C06 -
- Conditions for stop of trace recording STRING PowerOn
NBUP
- - CLEARCANCELALAR
M_M,
CLEARCANCELALAR
M_M...
- - 1/1
22706 TRACE_STOPTRACE_STEP EXP, C06 -
- CommandSequenzStep with which the recording ends STRING PowerOn
NBUP
- 2 , , , , , , , , , ... - - 1/1
