Machine data
2.3 Channel-specific machine data
Description: The machine data is only intended for diagnostics purposes.
Specific trace contents are selected with the MD data.
The entry SETALARM records the alarm environment and the block change in the
main run is also logged by means of BLOCK_CHANGE.
The machine data is additionally activated using the Cancel alarm key.
Description: The machine data is only intended for diagnostic purposes.
The MD datum defines which data are recorded in the trace file.
Description: The machine data is only intended for diagnostic use.
The MD data, together with TRACE_VARIABLE_NAME, determines which data are
recorded in the trace file.
It enables access to an array element.
E.g. use as an axis index when accessing axis data.
22708 TRACE_SCOPE_MASK EXP, C06 -
- Selects the contents of the trace file STRING PowerOn
NBUP
- - ... - - 1/1
22710 TRACE_VARIABLE_NAME --
- Definition of trace data STRING PowerOn
NBUP
- 10 "BL_NR",
"TR_POINT",
"EV_TYPE",
"EV_SRC",
"CS_ASTEP"...
- - 1/1
22712 TRACE_VARIABLE_INDEX EXP, C06 -
- Index for trace recording data DWORD PowerOn
NBUP
- 10 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0,
0x0, 0x0...
0 0xFFFF 1/1
