Machine data
2.3 Channel-specific machine data
Parameter Manual
172 Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
0: axial rotary axis offset is not considered.
1: axial rotary axis offset is considered.
2: axial rotary axis offset is considered until SZS.
SZS frames include transformed rotations around the rotary axis.
Description: Indicates the sign with which the rotary axis is taken into account in the
TRANSMIT transformation for the second agreed TRANSMIT transformation for
each channel.
Related to:
MD24910 $MC_TRANSMIT_ROT_SIGN_IS_PLUS_1
Description: Restriction of working area in front of/behind pole or no restriction, i.e.
traversal through pole.
The assigned values have the following meanings:
1: Working area of linear axis for positions >=0,
(if tool length compensation parallel to linear axis equals 0)
2: Working area of linear axis for positions <=0,
(if tool length compensation parallel to linear axis equals 0)
0: No restriction of working area. Traversal through pole.
Description: Indicates a basic offset of the tools zero for the 2nd TRANSMIT transforma-
tion. The offset is referenced to the geometry axes valid when TRANSMIT is
active. The basic offset is included with and without selection of the tool
length compensation. Programmed length corrections have an additive effect
with respect to the basic tool.
The index i takes the values 0, 1, 2 for the 1st to 3rd geometry axes.
Related to:
MD24920 $MC_TRANSMIT_BASE_TOOL_1
24955 TRANSMIT_ROT_AX_FRAME_2 C07 M1
- Rotary axis offset TRANSMIT 2 BYTE NEW CONF
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 1/1
24960 TRANSMIT_ROT_SIGN_IS_PLUS_2 C07 M1
- Sign of rotary axis for 2nd TRANSMIT transformation BOOLEAN NEW CONF
-
- - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE...
0 - 1/1
24961 TRANSMIT_POLE_SIDE_FIX_2 C07 M1
- Restriction of working range before/behind the pole, 2.
TRANSMIT
BYTE NEW CONF
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 1/1
24970 TRANSMIT_BASE_TOOL_2 C07 M1
mm Vector of base tool for 2nd TRANSMIT transformation DOUBLE NEW CONF
-
- 3 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0...
- - 1/1
