Machine data
2.3 Channel-specific machine data
Description: Indicates the sign with which the rotary axis is taken into account in the
TRANSMIT transformation for the first agreed TRANSMIT transformation for each
channel.
Related to:
MD24960 $MC_TRANSMIT_ROT_SIGN_IS_PLUS_2
Description: Restriction of the working area in front of/behind pole or no restriction,
i.e. traversal through the pole.
The assigned values have the following meanings:
1: Working area of linear axis for positions >=0,
(if tool length compensation parallel to linear axis equals 0)
2: Working area of linear axis for positions <=0,
(if tool length compensation parallel to linear axis equals 0)
0: No restriction of working area. Traversal through pole.
Description: Indicates a basic offset of the tools zero for the 1st TRANSMIT transforma-
tion. The offset is referenced to the geometry axes valid when TRANSMIT is
active. The basic offset is included with and without selection of the tool
length compensation. Programmed length corrections have an additive effect
with respect to the basic tool.
The index i takes the values 0, 1, 2 for the 1st to 3rd geometry axes.
Related to:
MD24970 $MC_TRANSMIT_BASE_TOOL_2
Description: Indicates the offset of the rotary axis for the second agreed TRANSMIT trans-
formation in degrees in relation to the neutral position while TRANSMIT is
active.
Related to:
MD24900 $MC_TRANSMIT_ROT_AX_OFFSET_1
24910 TRANSMIT_ROT_SIGN_IS_PLUS_1 C07 M1
- Sign of rotary axis for 1st TRANSMIT transformation BOOLEAN NEW CONF
-
- - TRUE, TRUE, TRUE,
TRUE, TRUE, TRUE,
TRUE...
0 - 1/1
24911 TRANSMIT_POLE_SIDE_FIX_1 C07 M1
- Restriction of working range in front of / behind the pole, 1.
TRANSMIT
BYTE NEW CONF
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 2 1/1
24920 TRANSMIT_BASE_TOOL_1 C07 M1
mm Vector of base tool for 1st TRANSMIT transformation DOUBLE NEW CONF
-
- 3 0.0, 0.0 , 0.0, 0.0,
0.0 , 0.0...
- - 1/1
24950 TRANSMIT_ROT_AX_OFFSET_2 C07 M1
degrees Offset of rotary axis for the 2nd TRANSMIT transformation DOUBLE NEW CONF
-
- - 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0...
- - 1/1
