Machine data
2.3 Channel-specific machine data
Parameter Manual
178
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
of M02/M30
Bit 13 = 1:Counter $AC_SPECIAL_PARTS is incremented by 1 with output of the
M command from MD PART_COUNTER_MCODE[2]
Bit 14 = 0:$AC_SPECIAL_PARTS also active with program test/block search
Bit 14 = 1:No machining $AC_SPECIAL_PARTS with program test/block search
Bit 15 = 1:counter $AC_SPECIAL_PARTS is incremented by 1 when jumping back
with GOTOS
Related to:
MD27882 $MC_PART_COUNTER_MCODE
Description: If part counting is activated via MD27880 $MC_PART_COUNTER, the count pulse
can be triggered by a special M command.
Only then are the values defined here taken into account:
Meaning:
The part counters are incremented by 1 in the NST signal output of the M com-
mand described, where:
MD27882 $MC_PART_COUNTER_MCODE[0] for $AC_TOTAL_PARTS
MD27882 $MC_PART_COUNTER_MCODE[1] for $AC_ACTUAL_PARTS
MD27882 $MC_PART_COUNTER_MCODE[2] for $AC_SPECIAL_PARTS
Description: With MD27920 $MC_TIME_LIMIT_NETTO_INT_TASK, the maximum runtime of the inter-
preter subtask is set. The interpreter subtask is started from the prepro-
cessing task. If the interpreter task does not end on its own within the time
set with MD27920 $MC_TIME_LIMIT_NETTO_INT_TASK, it will be stopped and con-
tinued after a preprocessing cycle.
27882 PART_COUNTER_MCODE C09 K1
- Workpiece counting with user-defined M command BYTE PowerOn
-
- 3 2, 2, 2, 2, 2, 2, 2, 2,
2, 2, 2, 2...
0 99 3/2
27920 TIME_LIMIT_NETTO_INT_TASK EXP, C01 -
s Runtime limit of interpreter subtask DOUBLE PowerOn
-
- - 0.005, 0.005, 0.005,
0.005, 0.005, 0.005...
0.001 0.100 7/0
