Machine data
2.1 Display machine data
Parameter Manual
18
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
Number of managed masks per cycle in manual mode of MM+
Description: Number of managed cutting edges in MM+
Description: The direction of spindle rotation is displayed inverted.
Description: Tool change increment MM+:
The selection field for fixed-point approach is selected or deselected by
default
Description: If the value is 1, the tool offset data can be measured in the X direction
with rotating spindle.
Description: Tool change increment MM+:
If the value is 1, input of a tool or cutting edge number is permissible.
Description: Input mode T no. in the cycle masks MM+:
0: No T no. input by the operator. T no. is automatically created from
SGUD.
>=1: T no. input by the operator
1096 MAX_NUM_CYCLE_MANUAL_MA --
- Number of managed masks per cycle in manual mode of MM+ DWORD Immediately
-
-- 9 1 9 3/3
1097 MAX_NUM_CUTT_EDGES_MANUAL_MA --
- Number of managed cutting edges in MM+ DWORD Immediately
-
-- 9 1 9 3/3
1098 INVERT_SPIN_ICON_MANUAL_MA --
- The direction of spindle rotation is displayed inverted. BOOLEAN Immediately
-
-- 1 0 1 3/2
1099 USE_FIXPOINT_MANUAL_MA --
- Tool change step MM+ BOOLEAN Immediately
-
-- 1 0 1 3/3
1100 MEAS_SPIN_ACTIV_MANUAL_MA --
- Measuring the tool offset data in the X direction with the
spindle rotating
BOOLEAN Immediately
-
-- 1 0 1 3/2
1101 USER_TOOL_CHG_MANUAL_MA --
- Tool change step MM+ BOOLEAN Immediately
-
-- 1 0 1 3/3
1102 CYC_TOOLNO_EDTMODE_MANUAL_MA --
- Input mode T no. in the cycle screen forms MM+ BOOLEAN Immediately
-
-- 1 0 1 3/3
