Page #181 background imageLoading...
Page #181 background image
Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
181
Machine data
2.3 Channel-specific machine data
Description: Number of channel-specific base frames per channel.
The value corresponds to the number of field elements for the predefined
field $P_CHBFR[].
Buffered memory is reserved for this.
Description: Bit mask for configuring channel-specific system frames included in the chan-
nel.
Bit 0: System frame for setting actual value and scratching
Bit 1: System frame for external work offset
Bit 2: System frame for TCARR aund PAROT
Bit 3: System frame for TOROT and TOFRAME
Bit 4: System frame for workpiece reference points
Bit 5: System frame for cycles
Bit 6: System frame for transformations
Bit 7:System frame $P_ISO1FR for ISO G51.1 Mirror
Bit 8:System frame $P_ISO2FR for ISO G68 2DROT
Bit 9:System frame $P_ISO3FR for ISO G68 3DROT
Bit 10:System frame $P_ISO4FR for ISO G51 Scale
Bit 11: System frame $P_RELFR for relative coordinate systems
Description: Bit mask for configuring channel-specific system frames in the data storage
(SRAM).
Bit 0: System frame for setting actual value and scratching
Bit 1: System frame for external work offset
Bit 2: System frame for TCARR aund PAROT
Bit 3: System frame for TOROT and TOFRAME
Bit 4: System frame for workpiece reference points
Bit 5: System frame for cycles
Bit 6: System frame for transformations
Bit 7:System frame $P_ISO1FR for ISO G51.1 Mirror
Bit 8:System frame $P_ISO2FR for ISO G68 2DROT
Bit 9:System frame $P_ISO3FR for ISO G68 3DROT
Bit 10:System frame $P_ISO4FR for ISO G51 Scale
Bit 11: System frame $P_RELFR for relative coordinate systems
28081 MM_NUM_BASE_FRAMES C02 M5,K2
- Number of base frames (SRAM) DWORD PowerOn
-
- - 1, 1, 1, 1, 1, 1, 1, 1... 0 16 1/1
28082 MM_SYSTEM_FRAME_MASK C02 M5,K2,W1
- System frames (SRAM) DWORD PowerOn
-
- - 0x7A1 0 0x00000FFF 1/0
28083 MM_SYSTEM_DATAFRAME_MASK C02 -
- System frames (SRAM) DWORD PowerOn
-
- - 0xF9F, 0xF9F, 0xF9F,
0xF9F, 0xF9F,
0xF9F...
0 0x00000FFF 1/1
