Machine data
2.3 Channel-specific machine data
Parameter Manual
182 Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
MM_MAX_TRACE_DATAPOINTS defines the size of an internal data buffer which
contains the trace recordings.
Description: This machine data defines how many blocks are set up for channel-specific
protection zones.
Related to:
MD28210 $MC_MM_NUM_PROTECT_AREA_ACTIVE
(number of simultaneously active protection zones)
MD18190 $MN_MM_NUM_PROTECT_AREA_NCK
(number of files for machine-related protection zones (SRAM))
References:
/FB/, A3, "Axis/Contour Tunnel Monitoring, Protection Zones"
Description: This machine data defines the number of protection zones that may be acti-
vated simultaneously for each channel.
It is not practical to enter a numerical value higher than MD18190
$MN_MM_NUM_PROTECT_AREA_NCK + MD28200 $MC_MM_NUM_PROTECT_AREA_CHAN.
Related to:
MD28200 $MC_MM_NUM_PROTECT_AREA_CHAN
(Number of blocks for channel-specific protection zones)
MD18190 $MN_MM_NUM_PROTECT_AREA_NCK
(Number of files for machine-related protection zones (SRAM))
References:
/FB1/ Function Manual Basic Functions; Axis Monitoring, Protection Zones (A3)
28180 MM_MAX_TRACE_DATAPOINTS EXP, C02, C06 -
- Length of the trace data buffer DWORD PowerOn
NBUP
- - 100, 100, 100, 100,
100, 100, 100, 100...
0 20000 1/1
28200 MM_NUM_PROTECT_AREA_CHAN C02, C06, C09 A3
- Number of files for channel-specific protection zones (SRAM) DWORD PowerOn
-
- - 10 0 10 1/1
28210 MM_NUM_PROTECT_AREA_ACTIVE C11, C02, C06,
C09
A3
- Number of simultaneously active protection zones in one
channel
DWORD PowerOn
-
- - 10 0 10 1/1
