Machine data
2.3 Channel-specific machine data
Description: This machine data defines for each channel how many internal contour elements
in total are held available for active protection zones.
Dynamic memory is used.
The MD affects the memory requirements for the activated protection zones.
This machine data is active only if MD28210 $MC_MM_NUM_PROTECT_AREA_ACTIVE is
not equal to 0.
Description: The values of the variables and machine data during diagnostics of the
motion-synchronous actions are saved to memory elements for storage in the
control. A motion-synchronous action uses up to the number of elements for as
many variables as are set with MD28241 $MC_MAXNUM_SYNC_DIAG_VAR.
The following are assigned:
• 1 element for each variable
• 1 element for each index
Example:
WHEN $R1 == 1 DO $R2 = $R[AC_MARKER[1]]
R1 = 2 elements, variable with written value 1 element, index "1" an element
R2 = 2 elements, variable with written value 1 Element, index "2" an element
AC_MARKER = 2 elements, variable with read value 1 element, index "1" an ele-
ment
R = 2 elements, variable with written value 1 element, index "1" an element
Total 8 elements.
Description: Maximum number of diagnostics variables per synchronized action.
28212 MM_NUM_PROTECT_AREA_CONTOUR C11, C02, C06,
C09
A3
- Elements for active protection zones (DRAM) DWORD PowerOn
-
- - 30, 30, 30, 30, 30, 30,
30, 30...
0 50 1/1
28240 MM_NUM_SYNC_DIAG_ELEMENTS N05, C02 -
- Number of diagnostic elements for expressions in
synchronized actions
DWORD PowerOn
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 32000 1/1
28241 MAXNUM_SYNC_DIAG_VAR N05 -
- Maximum number of diagnostics variables per synchronized
action
DWORD PowerOn
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 10000 1/1
