Machine data
2.3 Channel-specific machine data
Parameter Manual
184 Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
The expressions of the motion-synchronous actions are stored in memory ele-
ments in the control. A motion-synchronous action occupies at least 4 ele-
ments.
It occupies:
• 1 element for each operand in the condition
• >= 1 element for each action
• 2 elements for each assignment
• 1 element for each further operand in complex expressions.
One element occupies approx. 64 bytes.
The option "Synchronous actions stage 2" is required if the MD can be written
to.
Description: Defines the number of FCTDEF elements.
Description: The expressions of motion-synchronous actions are saved in memory elements
for storage in the control. Elements have to be reserved specifically for
strings within expressions.
Description: Panel size of $AC_PARAM.
Description: $AC_PARAM[] is stored in SRAM.
28250 MM_NUM_SYNC_ELEMENTS C02, - 2.8,6.1
- Number of elements for expressions in synchronized actions DWORD PowerOn
-
- - 90 0 159 1/0
28252 MM_NUM_FCTDEF_ELEMENTS C02 2.4,2.8,6.1
- Number of FCTDEF elements DWORD PowerOn
-
- - 3, 3, 3, 3, 3, 3, 3, 3... 0 100 1/1
28253 MM_NUM_SYNC_STRINGS C02, - -
- Number of strings for expressions in synchronized actions DWORD PowerOn
-
- - 200, 200, 200, 200,
200, 200, 200, 200...
0 32000 7/2
28254 MM_NUM_AC_PARAM C02 -
- Dimension of $AC_PARAM. DWORD PowerOn
-
- - 50, 50, 50, 50, 50, 50,
50, 50...
0 20000 1/1
28255 MM_BUFFERED_AC_PARAM C02 2.3,6.1
- $AC_PARAM[] is stored in SRAM. DWORD PowerOn
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 1 1/1
