Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
185
Machine data
2.3 Channel-specific machine data
Description: Number of channel-specific markers $AC_MARKER for motion-synchronous
actions.
DRAM or SRAM is required depending on MD28257 $MC_MM_BUFFERED_AC_MARKER.
Description: $AC_MARKER[] is stored in SRAM.
Description: Number of channel-specific time variables $AC_TIMER for motion-synchronous
actions (DRAM)
28256 MM_NUM_AC_MARKER C02 2.3,6.1
- Dimension of $AC_MARKER DWORD PowerOn
-
- - 8, 8, 8, 8, 8, 8, 8, 8... 0 20000 1/1
28257 MM_BUFFERED_AC_MARKER C02 2.3,6.1
- $AC_MARKER[] is stored in SRAM. DWORD PowerOn
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 1 1/1
28258 MM_NUM_AC_TIMER C02 2.3,2.4,6.1
- Number of time variables $AC_TIMER (DRAM) DWORD PowerOn
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 10000 1/1
