Machine data
2.3 Channel-specific machine data
Parameter Manual
188
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
Number of $AC_SYSTEM_ PARAM parameters for motion-synchronous actions.
Depending on MD28255 $MC_MM_BUFFERED_AC_PARAM, DRAM or SRAM is required.
Reserved for SIEMENS applications.
Description: Number of $AC_SYSTEM_MARKER markers for motion-synchronous actions.
Depending on MD28257 $MC_MM_BUFFERED_AC_MARKER, DRAM or SRAM is required.
Reserved for SIEMENS applications.
Description: Activation of recording for a user.
The users 0 and 1, and 5 - 9 are reserved for system functions.
The users 2, 3 and 4 can be used by OEM.
Description: Number of standard event types required in the ETP OPI block.
Description: Value:
0: Basic blocks with absolute values deactivated.
1: Basic blocks with absolute values activated;
A display buffer of the following size is created:
(MD28257 $MC_MM_BUFFERED_AC_MARKER + MD28070 $MC_MM_NUM_BLOCKS_IN_PREP) *
256 bytes
>= 128:Basic blocks with absolute values activated.
A display buffer of the following size is created:
(MD28060 $MC_MM_IPO_BUFFER_SIZE + MD28070 $MC_MM_NUM_BLOCKS_IN_PREP) *
<value>
28274 MM_NUM_AC_SYSTEM_PARAM EXP, C02 -
- Number of $AC_SYSTEM_ PARAM for motion-synchronous
actions
DWORD PowerOn
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 20000 1/1
28276 MM_NUM_AC_SYSTEM_MARKER EXP, C02 -
- Number of $AC_SYSTEM_MARKER for motion-synchronous
actions
DWORD PowerOn
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 20000 1/1
28300 MM_PROTOC_USER_ACTIVE C02 -
- Activation of logging for a user BOOLEAN PowerOn
-
- 10 TRUE, TRUE,
FALSE, FALSE,
FALSE, TRUE,
TRUE, TRUE,
FALSE...
0 - 1/1
28302 MM_PROTOC_NUM_ETP_STD_TYP C02 -
- Number of standard event types ETP DWORD PowerOn
-
- 10 28, 6, 0, 0, 0, 20,
20, 20, 0, 3...
28, 6, 0, 0, 0,
20, 20, 20...
59, 59... 1/1
28400 MM_ABSBLOCK EXP, C02 K1
- Activate basic blocks with absolute values DWORD PowerOn
-
- - 0, 0, 0, 0, 0, 0, 0, 0... 0 512 2/2
