Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
201
Machine data
2.4 Axis-specific machine data
Description: The machine data defines whether axis-specific interface signals are output
to the PLC while an axis is being simulated.
1: The axis-specific NC/PLC interface signals for a simulated axis are output
to the PLC.
This means that the user PLC program can be tested without the drives
having to be available.
0: The axis-specific NC/PLC interface signals for a simulated axis are not
output to the PLC.
All axis-specific NC/PLC interface signals are set to "0".
Not relevant for:
MD30130 $MA_CTRLOUT_TYPE (setpoint output type) = 1
30350 SIMU_AX_VDI_OUTPUT A01, A06 A2,G2,Z1
- Axis signals output for simulation axes BOOLEAN PowerOn
CTEQ
-- FALSE0 - 1/1
