Machine data
2.4 Axis-specific machine data
Parameter Manual
200
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
1: "Modulo 360 degrees" position display is active:
The position display of the rotary axis or spindle (for basic or machine
coordinate system) is defined as "Modulo 360 degrees". In the case of a pos-
itive direction of rotation, the control resets the position display inter-
nally to 0.000 degrees following each cycle of 359.999 degrees. The display
range is always positive and lies between 0 and 359.999 degrees.
0: Absolute position display is active:
In contrast to the modulo 360 degrees position display, absolute positions
are indicated by the absolute position display, e.g. +360 degrees after 1
rotation, and +720 degrees after 2 rotations, etc in the positive direction.
In this case, the display range is limited by the control in accordance with
the linear axes.
MD irrelevant for:
Linear axes MD30300 $MA_IS_ROT_AX = "0"
Related to:
MD30300 $MA_IS_ROT_AX = 1 "Axis is rotary axis"
Description: Defines the size of the modulo range. Default positions are accepted and dis-
played within this range. Useful modulo ranges are n * 360 degrees with inte-
ger n. Other settings are equally possible in principle. Attention should be
paid to having a useful relationship between the positions in the NC and the
mechanics (ambiguity). Velocity definitions are not affected by settings in
this MD.
Description: Defines the start position for the modulo range.
Example:
Start = 0 degree -> modulo range 0 <->360 degrees
Start = 180 degrees -> modulo range 180 <->540 degrees
Start = -180 degrees -> modulo range -180 <->180 degrees
30320 DISPLAY_IS_MODULO A01, A06, A11 R2,T1,K2
- Modulo 360 degrees displayed for rotary axis or spindle. BOOLEAN PowerOn
CTEQ
808d-me42 - FALSE, FALSE,
FALSE, TRUE
0 - 1/1
808d-me62 - FALSE, FALSE,
FALSE, TRUE, TRUE
0 - 1/1
808d-te42 - FALSE, FALSE,
FALSE, TRUE
0 - 1/1
808d-te62 - FALSE, FALSE,
FALSE, TRUE, TRUE,
TRUE
0 - 1/1
30330 MODULO_RANGE EXP, A01, - R2,T1,R1
degrees Size of modulo range. DOUBLE Reset
CTEQ
- - 360.0 1.0 360000000.0 1/1
30340 MODULO_RANGE_START EXP, A01 R1,R2
degrees Modulo range start position DOUBLE Reset
CTEQ
-- 0.0 - - 1/1
