Machine data
2.4 Axis-specific machine data
Parameter Manual
216 Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
If a positioning axis is programmed in the part program without specifying
the axis-specific feedrate, the feedrate entered in MD32060 $MA_POS_AX_VELO
is automatically used for this axis. The feedrate in MD32060 $MA_POS_AX_VELO
applies until an axis-specific feedrate is programmed in the part program for
this positioning axis.
MD irrelevant for:
MD32060 $MA_POS_AX_VELO is irrelevant for all axis types other than position-
ing axis.
Special cases:
If a ZERO velocity is entered in MD32060 $MA_POS_AX_VELO, the positioning
axis does not traverse if it is programmed without feed. If a velocity is
entered in MD32060 $MA_POS_AX_VELO that is higher than the maximum velocity
of the axis (MD32000 $MA_MAX_AX_VELO), the velocity is automatically
restricted to the maximum rate.
Description: > 0: Limitation of size of selected increment MD11330 $MN_JOG_INCR_SIZE
<Increment/VDI signal>Ü or SD41010 $SN_JOG_VAR_INCR_SIZE for the associated
machine axis
0: No limitation
Description: For the velocity override of positioning axes:
>0: Limitation of size of selected increment $MN_JOG_INCR_SIZEL<Increment/
VDI signal> 0 or SD41010 $SN_JOG_VAR_INCR_SIZE for the associated machine
axis
0: No limitation
32060 POS_AX_VELO A12, A04 H1,P2,K1,V1,2.4,6.2
mm/min, rev/
min
Initial setting for positioning axis velocity DOUBLE Reset
CTEQ
808d-me42 - 10000., 10000.,
10000., 36000.
(0./ 0.) (1.e300/ 1.e300) 1/1
808d-me62 - 10000., 10000.,
10000., 36000.,
36000.
(0./ 0.) (1.e300/ 1.e300) 1/1
808d-te42 - 10000., 10000.,
10000., 36000.
(0./ 0.) (1.e300/ 1.e300) 1/1
808d-te62 - 10000., 10000.,
10000., 36000.,
36000....
(0./ 0.) (1.e300/ 1.e300) 1/1
32080 HANDWH_MAX_INCR_SIZE A05, A10 H1
mm, degrees Limitation of selected increment DOUBLE Reset
CTEQ
-- 0.0 0.0 - 1/1
32082 HANDWH_MAX_INCR_VELO_SIZE A05, A10, A04 -
mm/min, rev/
min
Limitation for velocity override DOUBLE Reset
CTEQ
808d-me42 - 500., 500., 500., 1800. (0./ 0.) (1.e300/ 1.e300) 1/1
808d-me62 - 500., 500., 500.,
1800., 1800.
(0./ 0.) (1.e300/ 1.e300) 1/1
808d-te42 - 500., 500., 500., 1800. (0./ 0.) (1.e300/ 1.e300) 1/1
808d-te62 - 500., 500., 500.,
1800., 1800., 1800.
(0./ 0.) (1.e300/ 1.e300) 1/1
