Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
215
Machine data
2.4 Axis-specific machine data
Description: The value entered defines the revolutional feedrate of the axis in JOG mode
with rapid traverse override in relation to the revolutions of the master
spindle. This feedrate is active when SD41100 $SN_JOG_REV_IS_ACTIVE = 1.
(Revolutional feedrate active with JOG)
MD irrelevant for:
SD41100 $SN_JOG_REV_IS_ACTIVE = "0"
Related to:
SD41100 $SN_JOG_REV_IS_ACTIVE (revolutional feedrate with JOG active)
MD32050 $MA_JOG_REV_VELO (revolutional feedrate with JOG)
Description: The value entered defines the revolutional feedrate of the axis in JOG mode
in relation to the revolutions of the master spindle.
This feedrate is active when SD41100 $SN_JOG_REV_IS_ACTIVE= 1 (revolutional
feedrate active with JOG).
MD irrelevant for:
Linear feedrate; i.e. SD41100 $SN_JOG_REV_IS_ACTIVE = 0
Related to:
SD41100 $SN_JOG_REV_IS_ACTIVE
(revolutional feedrate for JOG active)
MD32040 $MA_JOG_REV_VELO_RAPID
(JOG revolutional feedrate with rapid traverse override)
32040 JOG_REV_VELO_RAPID A11, A04 H1,P2,R2,T1,V1,Z1
mm/rev Revolutional feedrate in JOG with rapid traverse override DOUBLE Reset
CTEQ
808d-me42 - 2.5, 2.5, 2.5, 1.0 0.0 - 1/1
808d-me62 - 2.5, 2.5, 2.5, 1.0, 1.0 0.0 - 1/1
808d-te42 - 2.5, 2.5, 2.5, 1.0 0.0 - 1/1
808d-te62 - 2.5, 2.5, 2.5, 1.0, 1.0,
1.0
0.0 - 1/1
32050 JOG_REV_VELO A11, A04 H1,P2,R2,T1,V1,Z1
mm/rev Revolutional feedrate in JOG DOUBLE Reset
CTEQ
808d-me42 - 0.5, 0.5, 0.5, 1.0 0.0 - 1/1
808d-me62 - 0.5, 0.5, 0.5, 1.0, 1.0 0.0 - 1/1
808d-te42 - 0.5, 0.5, 0.5, 1.0 0.0 - 1/1
808d-te62 - 0.5, 0.5, 0.5, 1.0, 1.0,
1.0
0.0 - 1/1
