Machine data
2.1 Display machine data
Parameter Manual
26
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
Color utilization display spindle area 3
Description: Type of measuring system: 1: probe, 2: opt. measuring procedure
Description: Absolute position probe X
Description: Absolute position probe Y
Description: Absolute position probe Z
Description: Limit value wear control on input
Description: Protection level User cycles for writing
Description: Tool monitoring protection level
368 SPINDLE_LOAD_BAR_COL3 --
- Color utilization display spindle area 3 BYTE Immediately
-
-- 9 0 15 3/3
369 PROBE_MODE --
- Type of measuring system: 1: probe, 2: opt. measuring
procedure
BOOLEAN Immediately
-
-- 1 0 2 3/3
370 TOOL_REF_PROBE_AXIS1 --
- Absolute position probe X DOUBLE Immediately
-
- - 0 -999999.999 999999.999 2/2
371 TOOL_REF_PROBE_AXIS2 --
- Absolute position probe Y DOUBLE Immediately
-
- - 0 -999999.999 999999.999 2/2
372 TOOL_REF_PROBE_AXIS3 --
- Absolute position probe Z DOUBLE Immediately
-
- - 9 -999999.999 999999.999 2/2
374 TOOL_WEAR_LIMIT_VALUE --
- Limit value wear control on input DOUBLE Immediately
-
- - 9.999 0 9.999 2/2
376 USER_CLASS_WRITE_CUS_DIR --
- Write user cycles protection level BYTE Immediately
-
-0 7 0 7 3/3
377 USER_CLASS_WRITE_TO_MON_DAT --
- Tool monitoring protection level BYTE Immediately
-
-0 7 0 7 3/2
