Siemens SINUMERIK 808D ADVANCED User Manual

Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
27
Machine data
2.1 Display machine data
Description: Select User Ladder View protection level
Description: 0: Standard Mode; spindle speed display
1: Constant cutting speed display when G96 is set
2: Mixed display
Description: Station address Drives
Description: Defines the access level for the CMA directory in the NCK
Description: Defines the display format of an indexing axis.
0 = indexing position
1 = type-spec. actual value
Description: Defines the access authorization for writing the location number in the tool
list
Description: Check box in tool list
378 USER_CLASS_LADDER_VIEW --
- Select User Ladder View protection level BYTE Immediately
-
-0 2 0 7 2/2
379 SPINDLE_DISP_MODE --
- Spindle display mode BYTE Immediately
-
-0 0 0 2 3/3
383 V24_PPI_ADDR_DRV1 --
- Station address Drives BYTE PowerOn
-
- 0 5 0 126 3/3
386 USER_CLASS_WRITE_CMA_DIR --
- Defines the access level for the CMA directory in the NCK BYTE Immediately
-
-- 7 1 7 2/2
391 DISPLAY_MODE_INDEXING_AXIS --
- Defines the display format of an indexing axis. DWORD Immediately
-
-- 0 0 1 7/2
392 USER_CLASS_WRITE_LOC_NO --
- Access authorization for writing the location number into the
tool list
BYTE Immediately
-
-- 7 0 7 3/2
395 COL_OVERSIZE_TYPE_CHECKBOX --
- Check box in tool list BOOLEAN Immediately
-
-- 1 0 1 3/3
