Machine data
2.4 Axis-specific machine data
Parameter Manual
260
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
SPIND_DEFAULT_ACT_MASK specifies the time at which the operating mode defined
in MD35020 $MA_SPIND_DEFAULT_MODE becomes effective. The initial spindle set-
ting can be assigned the following values at the following points in time:
0 POWER ON
1 POWER ON and NC program start
2 POWER ON and RESET (M2/M30)
Special cases:
If MD35040 $MA_SPIND_ACTIVE_AFTER_RESET = 1, the following supplementary con-
ditions are applicable:
• SPIND_DEFAULT_ACT_MASK should be set to 0
• If this is not possible, the spindle must be at a standstill prior to
activation.
Related to:
MD35020 $MA_SPIND_DEFAULT_MODE (initial spindle setting)
MD35040 $MA_SPIND_ACTIVE_AFTER_RESET (spindle active after reset)
Description: This data allows the "GWPS in every operating mode" function to be selected/
deselected.
SPIND_FUNC_RESET_MODE, bit 0 = 0 : "GWPS in every operating mode" is dese-
lected
SPIND_FUNC_RESET_MODE, bit 0 = 1 : "GWPS in every operating mode" is selected
35030 SPIND_DEFAULT_ACT_MASK A06, A10 S1
- Time at which initial spindle setting is effective BYTE Reset
CTEQ
- - 0x00 0 0x03 2/2
35032 SPIND_FUNC_RESET_MODE A06, A10 -
- Reset response of individual spindle functions DWORD PowerOn
CTEQ
- - 0x00 0 0x01 1/1
