Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
259
Machine data
2.4 Axis-specific machine data
Description: With this MD, a gear stage can be defined which can be loaded into the axis
mode during the transition with M70. The parameter set zero used in axis mode
is to be optimized on this gear stage.
Significance of the values:
0: There is no implicit gear stage change with M70.
The current gear stage is retained.
1 ... 5:
There is a change into gear stage (1...5) during the execution of M70.
During the transition into axis mode without M70, there is monitoring for
this gear stage and alarm 22022 is issued if necessary. The condition for a
gear stage change is the general release of the function in MD35010
$MA_GEAR_STEP_CHANGE_ENABLE.
Secondary conditions:
When changing from axis mode into spindle mode, the configured gear stage
continues to remain active. There is no automatic return to the last active
gear stage in spindle mode.
Description: SPIND_DEFAULT_MODE activates the set operating mode of the spindle at the
time specified in MD35030 $MA_SPIND_DEFAULT_ACT_MASK. The appropriate spin-
dle operating modes can be set with the following values:
0 Speed mode, position control deselected
1 Speed mode, position control activated
2 Positioning mode, no check for synchronized/referenced position on NC
start
3 Axis mode, MD34110 $MA_REFP_CYCLE_NR can be used to configure / deacti-
vate forced referencing on NC start
Corresponds with:
MD35030 $MA_SPIND_DEFAULT_ACT_MASK (activate spindle initial setting)
MD20700 $MC_REFP_NC_START_LOCK (NC start disable without reference point)
35014 GEAR_STEP_USED_IN_AXISMODE A01, A06, A11 -
- Gear stage for axis mode with M70 DWORD NEW CONF
CTEQ
-- 0 0 5 1/1
35020 SPIND_DEFAULT_MODE A06, A10 S1
- Initial spindle setting BYTE Reset
CTEQ
-- 0 0 3 2/2
