Machine data
2.4 Axis-specific machine data
Parameter Manual
264
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
Number of set gear stages.
The first gear stage is always available.
Corresponding MDs:
MD35010 $MA_GEAR_STEP_CHANGE_ENABLE (gear stages available/functions)
MD35012 $MA_GEAR_STEP_CHANGE_POSITION (gear stage change position)
MD35014 $MA_GEAR_STEP_USED_IN_AXISMODE (gear stage for axis mode with M70)
MD35110 $MA_GEAR_STEP_MAX_VELO (max. speed for gear stage change)
MD35120 $MA_GEAR_STEP_MIN_VELO (min. speed for gear stage change)
MD35130 $MA_GEAR_STEP_MAX_VELO_LIMIT (max. speed of gear stage)
MD35140 $MA_GEAR_STEP_MIN_VELO_LIMIT (min. speed of gear stage)
MD35200 $MA_GEAR_STEP_SPEEDCTRL_ACCEL (acceleration in speed control mode)
MD35210 $MA_GEAR_STEP_POSCTRL_ACCEL (acceleration in position control mode)
MD35310 $MA_SPIND_POSIT_DELAY_TIME (positioning delay time)
MD35550 $MA_DRILL_VELO_LIMIT (maximum speeds for tapping)
MD35092 $MA_NUM_GEAR_STEPS2 (number of gear stages 2nd gear stage data set)
Description: Number of set gear stages of the second gear stage data set for the function
'Tapping with G331/G332'.
Activation (only makes sense for master spindle on tapping): MD 35010
$MA_GEAR_STEP_CHANGE_ENABLE, bit 5.
The number of gear stages must not be the same in the first and second gear
stage data sets.
Corresponding MD:
MD35010 $MA_GEAR_STEP_CHANGE_ENABLE (gear stages available/functions)
MD35112 $MA_GEAR_STEP_MAX_VELO2 (2nd gear stage data set: max. speed for gear
stage change)
MD35122 $MA_GEAR_STEP_MIN_VELO2 (2nd gear stage data set: min. speed for gear
stage change)
MD35212 $MA_GEAR_STEP_POSCTRL_ACCEL2 (2nd gear stage data set: acceleration
in position control mode)
35090 NUM_GEAR_STEPS A06, A10 S1
- Number of gear stages DWORD Reset
-
-- 5 1 5 1/1
35092 NUM_GEAR_STEPS2 A06, A10 S1
- Number of gear stages of 2nd gear stage data set DWORD Reset
-
-- 5 1 5 1/1
