Machine data
2.4 Axis-specific machine data
Parameter Manual
282
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
With NC/PLC interface signal DB380x DBX2.3 (Blocking action active), blocking
monitoring is activated. If the monitored axis is forced away from the set-
point position (exact stop limit) by more than the blocking tolerance, alarm
26000 "Blocking monitoring" is output and the axis stopped.
Threshold value for clamping tolerance (half width of window).
Special cases:
The clamping tolerance must be greater than the "exact stop limit coarse".
Related to:
NC/PLC interface signal DB380x DBX2.3 (Blocking action active)
Description: This MD defines the standstill range for the axis velocity / spindle speed.
If the current actual velocity of the axis or the actual speed of the spindle
is less than the value entered in this MD, the NC/PLC interface signal DB390x
DBX1.4 (Axis/spindle stationary) is set.
To bring the axis/spindle to a standstill under control, the pulse enable
should not be removed until the axis/spindle is at a standstill. Otherwise
the axis will coast down.
Related to:
NC/PLC interface signal DB390x DBX1.4 (Axis/spindle stationary)
Description: Same meaning as 1st software limit switch plus, however the traversing range
limitation is in the negative direction.
The MD becomes active after reference point approach if the NC/PLC interface
signal DB380x DBX1000.2 (2nd software limit switch minus) is not set.
MD irrelevant:
if axis is not referenced.
Related to:
NC/PLC interface signal DB380x DBX1000.2 (2nd software limit switch minus)
36050 CLAMP_POS_TOL A05 A3,D1,Z1
mm, degrees Clamping tolerance DOUBLE NEW CONF
-
-- 0.5 0.0 - 2/2
36060 STANDSTILL_VELO_TOL A05, A04 TE1,A2,A3,D1,Z1
mm/min, rev/
min
Threshold velocity/speed 'Axis/spindle in stop' DOUBLE NEW CONF
-
808d-me42 - 5.00, 5.00, 5.00,
1800.00
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-me62 - 5.00, 5.00, 5.00,
1800.00, 360.00
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-te42 - 5.00, 5.00, 5.00,
1800.00
(0./ 0.) (1.e300/ 1.e300) 2/2
808d-te62 - 5.00, 5.00, 5.00,
1800.00, 360.00,
360.00
(0./ 0.) (1.e300/ 1.e300) 2/2
36100 POS_LIMIT_MINUS A03, A05, A11,
-
TE1,R2,T1,A3,Z1
mm, degrees 1st software limit switch minus DOUBLE NEW CONF
CTEQ
- - -1.0e8 - - 2/2
