Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
283
Machine data
2.4 Axis-specific machine data
Description: A software limit switch can be activated in addition to the hardware limit
switch. The absolute position in the machine axis system of the positive
range limit of each axis is entered.
The MD is active after reference point approach if NC/PLC interface signal
DB380x DBX1000.3 (2nd software limit switch plus) has not been set.
MD irrelevant:
if axis is not referenced.
Related to:
NC/PLC interface signal DB380x DBX1000.3 (2nd software limit switch plus)
Description: Same meaning as 2nd software limit switch plus, but the traversing range lim-
itation is in the negative direction.
The PLC can select whether software limit switch 1 or 2 is to be active by
means of the interface signal.
For example:
DB380x DBX1000.2 = 0 (1st software limit switch minus) active for 1st axis
DB380x DBX1000.2 = 1 (2nd software limit switch minus) active for 1st axis
MD irrelevant:
if axis is not referenced.
Related to:
NC/PLC interface signal DB380x DBX1000.2 (2nd software limit switch minus)
Description: This machine data can define a 2nd software limit switch position in the pos-
itive direction in the machine axis system. The PLC can select which of the
two software limit switches 1 or 2 is to be active by means of an interface
signal.
For example:
DB380x DBX1000.3 = 0 (1st software limit switch plus) active for 1st axis
DB380x DBX1000.3 = 1 (2nd software limit switch plus) active for 1st axis
MD irrelevant:
if axis is not referenced.
Related to:
NC/PLC interface signal DB380x DBX1000.3 (2nd software limit switch plus)
36110 POS_LIMIT_PLUS A03, A05, A11,
-
TE1,R2,T1,G2,A3,Z1
mm, degrees 1st software limit switch plus DOUBLE NEW CONF
CTEQ
-- 1.0e8 - - 2/2
36120 POS_LIMIT_MINUS2 A03, A05, - TE1,A3,Z1
mm, degrees 2nd software limit switch minus DOUBLE NEW CONF
CTEQ
- - -1.0e8 - - 2/2
36130 POS_LIMIT_PLUS2 A03, A05, - TE1,A3,Z1
mm, degrees 2nd software limit switch plus DOUBLE NEW CONF
CTEQ
-- 1.0e8 - - 2/2
