Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
297
Machine data
2.4 Axis-specific machine data
Description: Special gantry functions are set with this MD.
The MD is bit-coded, the following bits are assigned:
Bit 0 == 0:
Extended monitoring of the actual value difference is inactive.
An offset between master and slave axes occurring in tracking or BREAK_UP is
not taken into account in the monitoring of the actual value difference.
Alarm 10657 is not output if alarm 10563 occurs before Power OFF.
Bit 0 = 1:
Extended monitoring of the actual value difference is active.
An offset between master and slave axes occurring in tracking or BREAK_UP is
taken into account in the monitoring of the actual value difference.
Prerequisite: The gantry grouping must be rereferenced or resynchronized
after control startup.
Alarm 10657 is output if alarm 10563 occurs before Power OFF.
Bit 1 = 0:
Zero mark search direction of the slave axis analogous to MD 34010
Bit 1 = 1:
Zero mark search direction of the slave axis same as for master axis
Bit 2 = 0 :
Alarm 10655 "Synchronization in progress" is output
Bit 2 = 1
Alarm 10655 "Synchronization in progress" is not output
37150 GANTRY_FUNCTION_MASK A10 -
- Gantry functions DWORD Reset
-
808d-me42 - 0x00 0 0x7 -1/2
808d-me62 - 0x00 0 0x7 1/1
808d-te42 - 0x00 0 0x7 -1/2
808d-te62 - 0x00 0 0x7 1/1
