Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
307
NC setting data
Description: 1: The evaluation of the compensation table [t] is enabled.
The compensation table is now included in the calculation of the compensation
value for the compensation axis.
The compensation axis $AN_CEC_OUTPUT_AXIS can be taken from the table config-
uration.
The effective total compensation value in the compensation axis can be
adapted to the current machining by the targeted activation of tables (from
NC part programm or PLC user program).
The function does not become active until the following conditions have been
fulfilled:
• The option "Interpolatory compensation" is set
• The associated compensation tables in the NC user memory have been loaded
and enabled (SD41300 $SN_CEC_TABLE_ENABLEt] = 1)
• The current position measuring system is referenced (NC/PLC interface
signal DB390x DBX0.4 / .5 (Referenced/synchronized 1 or 2) = 1).
0: The evaluation of the sag compensation table [t] is not enabled.
Related to ....
MD18342 $MN_MM_CEC_MAX_POINTS[t] Number of interpolation points with sag
compensation
SD41300 $SN_CEC_TABLE_ENABLE[t] Evaluation of the sag compensation table
t is enabled
NC/PLC interface signal DB390x DBX0.4 (Referenced/synchronized 1)
NC/PLC interface signal DB390x DBX0.5 (Referenced/synchronized 2)
41300 CEC_TABLE_ENABLE -K3
- Compensation table enable BOOLEAN Immediately
-
808d-me42 6 FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1
808d-me62 8 FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1
808d-te42 6 FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1
808d-te62 8 FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1
