Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
311
NC setting data
Description: Additional channel-specific rapid traverse override in %. The value is calcu-
lated to the path depending on OPI variable enablOvrRapidFactor. The value
multiplies the other rapid traverse overrides (rapid traverse override of the
machine control panel, override default through synchronized actions
$AC_OVR).
Description: The value in this machine data is active if no scaling factor P has been pro-
grammed in the block.
Related to:
WEIGHTING_FACTOR_FOR_SCALE
Description: The value in this machine data is active if no factor for rotation R is pro-
grammed in the block.
Description: Distance between both tools of a double turret head.
Description: Value = TRUE:
A preprocessing stop is made with every block if SBL2 (single block with stop
after every block) is active. This suppresses the premachining of part pro-
gram blocks. This variant of the SBL2 is not true-to-contour.
This means that a different contour characteristic might be generated as a
result of the preprocessing stop than without single block or with SBL1.
Application: Debug mode for testing part programs.
42122 OVR_RAPID_FACTOR - MD12050
$MN_OVR_FACTOR_RAPID
_TRA,$AC_OVR
% Add. rapid traverse override can be specified through operation DOUBLE Immediately
-
- - 100., 100., 100., 100.,
100., 100., 100....
0.0 - 7/7
42140 DEFAULT_SCALE_FACTOR_P -FBFA
- Default scaling factor for address P DWORD Immediately
-
- - 1, 1, 1, 1, 1, 1, 1, 1... - - 7/7
42150 DEFAULT_ROT_FACTOR_R --
- Default rotation factor for address R DOUBLE Immediately
-
- - 0., 0., 0., 0., 0., 0., 0.,
0....
- - 7/7
42162 EXTERN_DOUBLE_TURRET_DIST -FBFA
- Double turret head tool distance DOUBLE Immediately
-
- - 0., 0., 0., 0., 0., 0., 0.,
0....
0.0 - 7/7
42200 SINGLEBLOCK2_STOPRE -BA
- Activate SBL2 debug mode BOOLEAN Immediately
-
- - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 7/7
