Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
315
NC setting data
grinding tools with tool point direction 0 or 9 or other undefined values are
treated like milling tools.
Note:
If the value of this setting data is changed within a program, we recommend
programming a preprocessing stop (stopre) before the description to avoid the
new value being used in program sections before that point. The opposite case
is not serious, i.e. if the setting data is written, subsequent NC blocks
will definitely access the new value.
Description: FALSE:
If two intersections are created on correction of the inner side of an
(almost) closed contour consisting of two successive circle blocks or a cir-
cle and a linear block, the intersection that lies on the first part contour
nearer to the block end will be selected as per the default behavior.
A contour will be considered as (almost) closed if the distance between the
starting point of the first block and the end point of the second block is
smaller than 10% of the active compensation radius, but not larger than 1000
path increments (corresponds to 1mm to 3 decimal places).
TRUE:
Under the same condition as described above, the intersection that lies on
the first part contour nearer to block start is selected.
Description: Setting data for additional limitation of (tangential) path acceleration
Related to ...
MD32300 $MA_MAX_AX_ACCEL
SD42502 $SC_IS_SD_MAX_PATH_ACCEL
Description: SD42500 $SC_SD_MAX_PATH_ACCEL is included in the limit calculations if
SD42502 $SC_IS_SD_MAX_PATH_ACCEL=TRUE
Related to ...
SD42500 $SC_SD_MAX_PATH_ACCEL
42496 CUTCOM_CLSD_CONT --
- Tool radius compensation behavior with closed contour BOOLEAN Immediately
-
- - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 3/3
42500 SD_MAX_PATH_ACCEL -B2
m/s² maximum path acceleration DOUBLE Immediately
-
- - 10000., 10000.,
10000., 10000.,
10000....
1.0e-6 - 1/1
42502 IS_SD_MAX_PATH_ACCEL -B2
- Evaluate SD42500 $SC_SD_MAX_PATH_ACCEL BOOLEAN Immediately
-
- - FALSE, FALSE,
FALSE, FALSE,
FALSE, FALSE...
0 - 1/1
