Detailed descriptions of interface signals
4.3 Signals from / to HMI
Parameter Manual
332
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
DB1700
DBX1.3
Feedrate override selected for rapid traverse
Signal(s) to channel (HMI → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The feedrate override switch should also be active as rapid traverse
override switch.
Override values above 100% are limited to the maximum value for 100%
rapid traverse override.
The IS "Feedrate override for rapid traverse selected" is automatically
entered from the operator panel into the PLC interface and is transferred
from the basic PLC program to the PLC interface signal "Rapid traverse
override active".
Further, the IS "Feedrate override" (DB3200 DBB4) is copied from the
basic PLC program into the IS "Rapid traverse override" (DB3200 DBB5).
Signal state 0 The feedrate override switch should not be activated as rapid traverse
override switch.
Application The signal is used when no separate rapid traverse override switch is
available.
Note for the reader Function Manual Basic Functions V1
DB1700
DBX1.7
Program test selected
Signal(s) from HMI → PLC
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 Program control program test has been selected from the operator interface.
This does not activate the function.
Signal state 0 Program control program test has not been selected from the operator
interface.
corresponding to ... IS "Activate program test"
IS "Program test active"
Note for the reader Function Manual Basic Functions V1
DB1700
DBX2.0 to 3.1
Skip block selected
Signal(s) from HMI → PLC
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 Program control – skip block – has been selected from the operator
interface. This does not activate the function.
Signal state 0 Program control – skip block – has not been selected from the operator
interface.
corresponding to ... IS "Activate skip block"
Note for the reader Function Manual Basic Functions K1
