Siemens SINUMERIK 808D ADVANCED User Manual

Detailed descriptions of interface signals
4.7 Channel-specific signals
Parameter Manual
354 Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
DB3200
DBB5
Rapid traverse override
Signal(s) to channel (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
Gray coding for rapid traverse override
Switch
setting
Code Rapid traverse override
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
00001
00011
00010
00110
00111
00101
00100
01100
01101
01111
01110
01010
01011
01001
01000
11000
11001
11011
11010
11110
11111
11101
11100
10100
10101
10111
10110
10010
10011
10001
10000
0.0
0.01
0.02
0.04
0.06
0.08
0.10
0.20
0.30
0.40
0.50
0.60
0.70
0.75
0.80
0.85
0.90
0.95
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
corresponding to ... IS "Rapid traverse override active" (DB3200 DBX6.6)
Note for the reader Function Manual Basic Functions V1
