Detailed descriptions of interface signals
4.7 Channel-specific signals
Parameter Manual
362
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Signal state 1 GOTOS in the part program initiates a return jump to the program start. The
program is then processed again.
Signal state 0 GOTOS does not initiate a return jump. Program execution is continued
with the next part program block after GOTOS.
corresponding to ... MD27860 PROCESSTIMER_MODE
MD27880 PART_COUNTER
Note for the reader Function Manual Basic Functions H1
DB3200
DBX1000.0 to .1
DBX1004.0 to .1
DBX1008.0 to .1
Activate handwheel (1 and 2)
for axis 1 in the Work
for axis 2 in the Work
for axis 3 in the Work
Signal(s) to channel (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
These PLC interface signals are used to define whether this geometry axis
is assigned to handwheel 1 or 2 or is not assigned to any handwheel.
Only one handwheel can be assigned to an axis at any one time.
If several interface signals "activate handwheel" are set, then 'Handwheel 1'
has a higher priority than 'Handwheel 2'.
Note:
Two geometry axes can be simultaneously traversed using handwheels 1 to
2!
Signal state 0 or edge
change 1 → 0
Neither handwheel 1 or 2 is assigned to this axis.
Application The PLC user program can use this interface signal to interlock the
influence on the geometry axis when turning a handwheel.
corresponding to ... IS "Handwheel active" 1 to 2
for axis 1 in the Work: DB3300 DBX1000.0 to .2
for axis 2 in the Work: DB3300 DBX1004.0 to .2
for axis 3 in the Work: DB3300 DBX1008.0 to .2
Note for the reader Function Manual Basic Functions H1
DB3200
DBX1000.3
DBX1004.3
DBX1008.3
Feedrate stop for axes in the Work
Signal(s) to channel (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
The signal is only active in the JOG mode (axes are traversed in the Work).
• The signal triggers a feedrate stop for the axis. For a traversing axis, this
signal brings it to a standstill with a controlled braking (ramp stop). No
alarm is output.
• The position control is kept, i.e. the following error is eliminated.
• If a travel request is issued for an axis with an active "feedrate stop",
then this is kept. This queued travel request is executed immediately
after the "feedrate stop" has been withdrawn.
