Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
363
Detailed descriptions of interface signals
4.7 Channel-specific signals
Signal state 0 or edge
change 1 → 0
• The feedrate is enabled for the axis.
• If a travel request ("travel command") is active when the "feedrate stop"
is withdrawn, this is executed immediately.
Note for the reader Function Manual Basic Functions V1
DB3200
DBX1000.4
DBX1004.4
DBX1008.4
Traversing key disable
for axis 1 in the Work
for axis 2 in the Work
for axis 3 in the Work
Signal(s) to channel (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
The plus and minus traversing keys have no effect on the geometry axes in
question. It is thus not possible to traverse the geometry axis in JOG with
the traversing keys on the machine control panel.
If the traversing key disable is activated while traversing, the geometry axis
is stopped.
Signal state 0 The plus and minus traversing keys are enabled.
Application It is thus possible, depending on the operating state, to interlock traversing
of the geometry axis in JOG mode using the traversing keys from the PLC
user program.
corresponding to ... IS "Traversing key plus" and " ... minus"
for axis 1 in the Work (DB3200 DBX1000.7 and .6 )
for axis 2 in the Work (DB3200 DBX1004.7 and .6 )
for axis 3 in the Work (DB3200 DBX1008.7 and .6 )
Note for the reader Function Manual Basic Functions H1
DB3200
DBX1000.5
DBX1004.5
DBX1008.5
Rapid traverse override
for axis 1 in the Work
for axis 2 in the Work
for axis 3 in the Work
Signal(s) to channel (PLC → NCK)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
If, together with the "Traversing key plus" or "Traversing key minus" the
PLC interface signal "Rapid traverse override" is issued, then the geometry
axis that is addressed traverses with the rapid traverse - intended for JOG -
of the associated machine axis (e.g.: X → X1).
This rapid traverse velocity is defined using MD32010 JOG_VELO_RAPID.
The rapid traverse override is effective in the JOG mode for the following
versions:
• for continuous travel
• for incremental travel
If rapid traverse override is active, the velocity can be modified with the
rapid traverse override switch.
Signal state 0 or edge
change 1 → 0
The geometry axis traverses with the specified JOG velocity (SD41110
JOG_SET_VELO or MD32020 JOG_VELO).
Signal irrelevant for ...
• AUTOMATIC and MDI modes
• Reference point approach (JOG mode)
