Machine data
2.2 General machine data
Parameter Manual
38
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
M17 or RET.
Bit15=1
Means that there is no stop in any user ASUB block. Exception: The single
block stop has been explicitly activated via the SBLON command.
There are three different internal ASUBs that are triggered by different
events.
- Repos: In the case of the events: change of operating mode to a manual mode
(JOG, JOGREF,...) unless MODESWITCH_MASK is not set, switch skip block on and
off, activate machine data, switch-on overstore, axis replacement, subroutine
level cancelation, switch-on single block, switch dry run feedrate on and
off, alarm with compensation block.
- Return: Delete distance-to-go, switchover after TEACH-IN, or deselection of
MDI with corresponding MODESWITCH_MASK.
Bit16=1
Activating SERUPRO (search run via prog test) prevents stopping at single
blocks.
Related to:
MD20117 $MC_IGNORE_SINGLEBLOCK_ASUP
Description: DRYRUN_MASK == 0
Dryrun can only be switched on or off at the end of the block.
When DRYRUN_MASK = 1 is set, the dry run feedrate can also be activated dur-
ing program execution (in the part program block).
NOTICE!
After activating dry run feedrate, the axes are stopped for the duration of
the reorganization process.
DRYRUN_MASK == 2
Dryrun can be switched on or off in every phase and the axes are not stopped.
NOTICE:
However, the function does not become active until a "later" block in the
program execution and this is with the next (implicit) StopRe block.
Related to:
SD42100 $SC_DRY_RUN_FEED
10704 DRYRUN_MASK N01 V1
- Dry run feedrate activation BYTE PowerOn
-
-- 0 0 2 1/1
