Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
39
Machine data
2.2 General machine data
Description: If SLASH_MASK = 0, skip block can only be activated when stopped at the end
of the block
If SLASH_MASK = 1, skip block can also be activated during program execution.
NOTICE!
After activating skip block, the axes are stopped for the duration of the
reorganization process.
If SLASH_MASK = 2 ,skip block can be activated in every phase.
Notice!
However, the function does not become active until a "later" block in the
program execution, and this is with the next (implicit) StopRe block.
Description: Bit-coded mask for program test
Bit 0 == 1 Program test cannot be deselected in 'Stopped' program status.
Bit 1 == 1 Enable to activate the program test using the PI
command_N_NCKMOD
Bit 2 == 1 Activation of program test with accelerated feed in normal pro-
gram processing.
Only released for test purposes
Bit 3 == 1 Activation of program test with accelerated feed in the simula-
tion.
Bit 4 == 1 Activation of accelerated program test takes place in synchro-
nized multi-channel mode.
Bit 5..31 As of yet unused.
Program test with normal processing is always activated via the VDI inter-
face.
Program test in simulation is always activated via the NCKMode PI.
Program test block search is always activated via the Find-Pi.
10706 SLASH_MASK N01 PG,A2
- Activation of block skip BYTE PowerOn
-
-- 0 0 2 1/1
10707 PROG_TEST_MASK N01 K1
- Program test mode DWORD PowerOn
-
- - 0x1 0 0x1B 1/1
