Detailed descriptions of interface signals
4.8 Axis / spindle-specific signals
corresponding to ... SD41100 JOG_REV_IS_ACTIVE
(revolutional feedrate for JOG active)
SD42600 JOG_FEED_PER_REV_SOURCE
(In the JOG mode revolutional feedrate for geometry axes, on which the
frame with rotation acts)
SD43300 ASSIGN_FEED_PER_REV_SOURCE
(Revolutional feedrate for position axes/spindles)
MD32040 JOG_REV_VELO_RAPID
(Revolutional feedrate for JOG with rapid traverse override)
MD32050 JOG_REV_VELO (revolutional feedrate for JOG)
Note for the reader Function Manual, Expansion Functions P2
Function Manual, Special Functions M3
DB390x
DBX2.3
Measurement active
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The "Measuring" function is active.
The instantaneous measurement status of the axis is displayed (measuring
set with this axis is running).
Signal state 0 The "Measuring" function is not active.
Note for the reader Function Manual, Expansion Functions M5
DB390x
DBX2.4
Activate travel to fixed endstop
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The "Travel to fixed stop" function is active.
Signal state 0 The "Travel to fixed stop" function is not active.
Note for the reader Function Manual Basic Functions F1
DB390x
DBX2.5
Fixed stop reached
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 The fixed stop was reached after selecting the "FXS" function.
Signal state 0 The fixed stop has still not been reached after selecting the "FXS" function.
Note for the reader Function Manual Basic Functions F1
DB390x
DBX4.0 to .1
Handwheel active (1 to 2)
Signal(s) from axis / spindle (NCK → PLC)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 These PLC interface signals provide feedback as to whether this machine
axis is assigned to handwheel 1 or 2 or is not assigned to any handwheel.
Only one handwheel can be assigned to an axis at any one time.
If several interface signals "activate handwheel" are set, then 'Handwheel 1'
has a higher priority than 'Handwheel 2'.
If the assignment is active, then the machine axis can be traversed using
the handwheel in the JOG mode.
