Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
461
SINAMICS V70 parameters
6.2 V70 parameters on BOP
r0037
[0...19]
Servo drive temperatures - - - °C Float - -
Description: Displays the temperatures in the servo drive.
• [0] = Inverter, maximum value
• [1] = Depletion layer maximum value
• [2] = Rectifier maximum value
• [3] = Air intake
• [4] = Interior of servo drive
• [5] = Inverter 1
• [6] = Inverter 2
• [7] = Inverter 3
• [8] = Inverter 4
• [9] = Inverter 5
• [10] = Inverter 6
• [11] = Rectifier 1
• [12] = Rectifier 2
• [13] = Depletion layer 1
• [14] = Depletion layer 2
• [15] = Depletion layer 3
• [16] = Depletion layer 4
• [17] = Depletion layer 5
• [18] = Depletion layer 6
• [19] = Cooling system liquid intake
The value of -200 indicates that there is no measuring signal.
• r0037[0]: Maximum value of the inverter temperatures (r0037[5...10]).
• r0037[1]: Maximum value of the depletion layer temperatures (r0037[13...18]).
• r0037[2]: Maximum value of the rectifier temperatures (r0037[11...12]).
The maximum value is the temperature of the hottest inverter, depletion layer, or rectifier.
r0068 Absolute current actual value - - - Arms Float - -
Description: Displays actual absolute current.
For A_INF, S_INF the following applies:
• The value is updated with the current controller sampling time.
The following applies for SERVO:
• The value is updated with a sampling time of 1 ms.
• Absolute current value = sqrt(Iq^2 + Id^2)
• The absolute current actual value is available smoothed (r0027) and unsmoothed (r0068).
Dependency: r0027
Par. No. Name Min Max Factory
setting
Unit Data type Effective Can be
changed
