SINAMICS V70 parameters
6.2 V70 parameters on BOP
Parameter Manual
462
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
r0069
[0...6]
Phase current actual value - - - A Float - -
Description: Displays the measured actual phase currents as peak value.
• [0] = Phase U
• [1] = Phase V
• [2] = Phase W
• [3] = Phase U offset
• [4] = Phase V offset
• [5] = Phase W offset
• [6] = Total U, V, W
In indices 3 ... 5, the offset currents of the 3 phases, which are added to correct the phase currents, are
displayed.
The sum of the 3 corrected phase currents is displayed in index 6.
r0079
[0...1]
Torque setpoint total - - - Nm Float - -
Description: Displays the torque setpoint at the output of the speed controller (before clock cycle interpolation).
• [0]: Unsmoothed
• [1]: Smoothed
r0632 Motor temperature model,
stator winding temperature
---°CFloat--
Description: Displays the stator winding temperature of the motor temperature model.
p0918 Drive Bus address 10 15 10 - U16 RE T
Description: Displays or sets the Drive Bus address for Drive Bus interface on the servo drvie.
The address can be set as follows:
Using p0918
• Only if the address 00 hex, 7F hex, 80 hex, or FF hex has been set using the address switch.
• The address is saved in a non-volatile fashion using the function "copy from RAM to ROM".
• A change only becomes effective after a POWER ON.
p1058 Jog 1 speed setpoints 0 210000.0
00
100 rpm Float IM T
Description: Sets the speed/velocity for jog 1. Jogging is level-triggered and allows the motor to be
incrementally moved.
p1082 Maximum speed 0.000 210000.0
00
1500.00
0
rpm Float IM T
Description: Sets the highest possible speed.
Dependency: p0322
p1083 Speed limit in positive direction
of rotation
0.000 210000.0
00
210000.
000
rpm Float IM T, U
Description: Sets the maximum speed for the positive direction.
p1086 Speed limit in negative
direction of rotation
-
210000.0
00
0.000 -
210000.
000
rpm Float IM T, U
Description: Sets the speed limit for the negative direction.
Par. No. Name Min Max Factory
setting
Unit Data type Effective Can be
changed
