Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
53
Machine data
2.2 General machine data
Description: Configuration for programming the tool change in an external programming lan-
guage:
Bit0=0:
Only active for the ISO mode turning: The tool number and offset number are
programmed in the T word. $MN_DIGITS_TOOLNO defines the number of leading
digits, which form the tool number.
Example:
$MN_DIGITS_TOOLNO = 2
T=1234 ; tool number 12,
; offset number 34
Bit0=1:
Only active in the ISO mode turning: Only the tool number is programmed in
the T word. Offset number == tool number. $MN_DIGITS_TOOLNO is irrelevant.
Example:
T=12 ; tool number 12
; offset number 12
Bit1=0:
Only active in the ISO mode turning:
If the number of digits programmed in the T word is the same as the number
defined in MD10888 $MN_EXTERN_DIGITS_TOOL_NO, then leading 0s are added
Bit1=1:
Is only active for the ISO mode turning:
If the number of digits programmed in the T word is the same as the number of
digits specified in MD10888 $MN_EXTERN_DIGITS_TOOL_NO, the programmed number
is the offset number and tool number
Bit2=0:
Is only active for the ISO mode turning: ISO T offset selection only with D
(Siemens cutting edge number)
Bit2=1:
Is only active for the ISO mode turning: ISO T offset selection only with H
($TC_DPH[t,d])
Bit6=0:
The offset memories for the tool length and tool radius are linked so that
tool length and tool radius are always selected when either H or D is pro-
grammed.
Bit6=1:
The offset memories for the tool length and tool radius are not linked, so
that the number of the tool length value is selected when H is programmed,
and the number of the tool radius value is selected when D is programmed.
Bit7=0:
Is only active for the ISO mode turning. If T substitution ( MD10717
$MN_T_NO_FCT_CYCLE_NAME ) is active, the H number programmed in the T word is
transferred to the cycle in the variable $C_D.
10890 EXTERN_TOOLPROG_MODE N12 FBFA
- Tool change programming for external language DWORD PowerOn
-
808d-me42 - 0x0 0 - 2/2
808d-me62 - 0x0 0 - 2/2
808d-te42 - 0x04 0 - 2/2
808d-te62 - 0x04 0 - 2/2
