Machine data
2.2 General machine data
Parameter Manual
52
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
This machine data is active for external programming languages,
that is if MD18800 $MN_MM_EXTERN_LANGUAGE = 1.
This machine data specifies which incremental system is active:
0: Incremental system IS-B = 0.001 mm/degree
= 0.0001 inch
1: Incremental system IS-C = 0.0001 mm/degree
= 0.00001 inch
Related to:
MD10884 $MN_EXTERN_FLOATINGPOINT_PROG
Description: This machine data is only active when MD10880 $MN_MM_EXTERN_CNC_SYSTEM == 2.
Number of digits of the tool number in the programmed T word.
From the programmed T word, the number of leading digits specified in MD10888
$MN_EXTERN_DIGITS_TOOL_NO are interpreted as the tool number.
The following digits address the offset memory.
Entering a value > 0 in MD10889 $MN_EXTERN_DIGITS_OFFSET_NO renders MD10888
$MN_EXTERN_DIGITS_TOOL_NO ineffective.
MD10889 $MN_EXTERN_DIGITS_OFFSET_NO has priority over MD10888
$MN_EXTERN_DIGITS_TOOL_NO.
Description: This machine data is only active when MD10880 $MN_MM_EXTERN_CNC_SYSTEM == 2.
Number of digits of the offset number in the programmed T word.
From the programmed T word, the number of leading digits specified in MD10889
$MN_EXTERN_DIGITS_OFFSET_NO are interpreted as the offset number.
The following digits address the tool number.
10886 EXTERN_INCREMENT_SYSTEM N12 FBFA
- Incremental system in external language mode BOOLEAN PowerOn
-
-- FALSE0 - 2/2
10888 EXTERN_DIGITS_TOOL_NO N12 FBFA
- Digits for T number in ISO mode BYTE PowerOn
-
-- 2 0 8 2/2
10889 EXTERN_DIGITS_OFFSET_NO N12 FBFA
- Digits for offset number in ISO mode BYTE PowerOn
-
-- 0 0 8 2/2
