Machine data
2.2 General machine data
Description: Definition of the GCodeSystem to be actively executed in ISO_3 Mod (turning):
Value = 0 : ISO_3: Code system B
Value = 1 : ISO_3: Code system A
Value = 2 : ISO_3: Code system C
Description: List of G commands of external NC languages which have been reconfigured by
the user.
The implemented G commands are to be taken from the current Siemens documen-
tation for this programming language.
The list is structured as follows:
Even address: G command to be changed
Subsequent odd address: New G command
Only G codes can be reconfigured, e.g.: G20, G71.
Description: This MD defines how programmed values without a decimal point are evaluated:
0: 'Standard notation', values without a decimal point are interpreted in
internal units. For example, X1000 = 1 mm (for 0.001 mm input resolution)
X1000.0 = 1000 mm
1: 'Pocket calculator notation', values without a decimal point are inter-
preted as mm, inches or degrees. For example, X1000 = 1000 mm X1000.0 = 1000
mm
Related to:
MD10886 $MN_EXTERN_INCREMENT_SYSTEM
10881 MM_EXTERN_GCODE_SYSTEM N01, N12 FBFA
- ISO_3 Mode: GCodeSystem DWORD PowerOn
-
808d-me42 - 0 0 2 0/0
808d-me62 - 0 0 2 0/0
808d-te42 - 1 0 2 1/1
808d-te62 - 1 0 2 1/1
10882 NC_USER_EXTERN_GCODES_TAB N12 FBFA
- List of user-specific G commands of an external NC language STRING PowerOn
-
- 60 ... - - 1/1
10884 EXTERN_FLOATINGPOINT_PROG N12 FBFA
- Evaluation of programmed values without decimal point BOOLEAN PowerOn
-
- - TRUE 0 - 2/2
