Machine data
2.2 General machine data
Parameter Manual
50
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
Name of the subprogram started by a call via the M function defined by
MD10814 $MN_EXTERN_M_NO_MAC_CYCLE[n].
Description: G number for calling a macro.
The name of the subprogram is stated in MD10817
$MN_EXTERN_G_NO_MAC_CYCLE_NAME[n].
If the G function specified with MD10816 $MN_EXTERN_G_NO_MAC_CYCLE[n] is pro-
grammed in a part program block, the subprogram defined in MD10817
$MN_EXTERN_M_NO_MAC_CYCLE_NAME[n] is started. All addresses programmed in
the block are written in the corresponding $C_xx variables.
No subprogram call is executed if a subprogram call is already active via an
M/G macro or an M replacement. If a standard G function is programmed in this
case, this code is executed. Otherwise, alarm 12470 is issued.
MD10816 $MN_EXTERN_G_NO_MAC_CYCLE[n] is only active in the external language
mode G291.
Only a single subprogram call may be included in any one block. This means
that only a single M/G function replacement may be programmed in a block, and
no additional subprogram (M98) or cycle call may be included in the block.
Furthermore, a subprogram return and a part program end are not permitted in
the same block.
Alarm 14016 is issued in case of a conflict.
Description: Name of the subprogram started by call via the G function defined by MD10816
$MN_EXTERN_G_NO_MAC_CYCLE[n].
Description: Number of the interrupt input starting an asynchronous subprogram activated
in ISO mode. (M96 <program number>)
Description: Number of the interrupt input triggering rapid retraction to the position
programmed with G10.6 in ISO mode.
10815 EXTERN_M_NO_MAC_CYCLE_NAME EXP, N12 H2
- Name of subroutine for M function macro call STRING PowerOn
-
- 30 ... - - 2/2
10816 EXTERN_G_NO_MAC_CYCLE EXP, N12 FBFA
- Macro call via G function DOUBLE PowerOn
-
- 50 -1., -1., -1., -1., -1., -1.,
-1., -1....
- - 2/2
10817 EXTERN_G_NO_MAC_CYCLE_NAME EXP, N12 FBFA
- Name of subroutine for G function macro call STRING PowerOn
-
- 50 ... - - 2/2
10818 EXTERN_INTERRUPT_NUM_ASUP EXP, N12 FBFA
- Interrupt number for ASUB start (M96) BYTE PowerOn
-
-- 1 1 8 1/1
10820 EXTERN_INTERRUPT_NUM_RETRAC EXP, N12 FBFA
- Interrupt number for rapid retraction (G10.6) BYTE PowerOn
-
-- 2 1 8 2/2
