Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
49
Machine data
2.2 General machine data
Description: This machine data defines the assignment of measurement inputs 1 and 2 to the
P numbers programmed with G31 P1 ( - P4). The machine data is bit-coded. Only
bits 0 and 1 are evaluated. For example, if bit 0 = 1 in MD10810
$MN_EXTERN_MEAS_G31_P_SIGNAL[1], the 1st measurement input is activated with
G31 P2. If MD10810 $MN_EXTERN_MEAS_G31_P_SIGNAL[3]=2, the 2nd measurement
input is activated with G31 P4.
Bit 0: = 0, Do not evaluate measurement input 1 with G31 P1 (- P4)
Bit 0: = 1, Activate measurement input 1 with G31 P1 (- P4)
Bit 1: = 0, Do not evaluate measurement input 2 with G31 P1 (- P4)
Bit 1: = 1, Activate measurement input 2 with G31 P1 (- P4)
Description: A macro is called with this M number.
The name of the subprogram is stated in MD10815
$MN_EXTERN_M_NO_MAC_CYCLE_NAME[n].
If the M function specified with MD10814 $MN_EXTERN_M_NO_MAC_CYCLE[n] is pro-
grammed in a part program block, the subprogram defined in MD10815
$MN_EXTERN_M_NO_MAC_CYCLE_NAME[n] is started. All addresses programmed in
the block are written into the corresponding variables.
If the M function is programmed again in the subprogram, there is no longer a
replacement by a subprogram call.
MD10814 $MN_EXTERN_M_NO_MAC_CYCLE[n] is only active in the external language
mode G291.
The subprograms configured with MD10815 $MN_EXTERN_M_NO_MAC_CYCLE_NAME[n]
must not be active simultaneously in a block (part program line), i.e. only
one M function replacement can become active in any one block. Neither an M98
nor a modal subprogram call may be programmed in the block with the M func-
tion replacement.
Subprogram return and the part program end are also not permitted. Alarm
14016 is issued in case of a conflict. Restrictions: see MD10715
$MN_M_NO_FCT_CYCLE
Related to:
MD10714 $MN_M_NO_FCT_EOP,
MD10715 $MN_M_NO_FCT_CYCLE,
MD20094 $MC_SPIND_RIGID_TAPPING_M_NR,
MD22254 $MC_AUXFU_ASSOC_M0_VALUE
MD10814 $MN_EXTERN_M_NO_MAC_CYCLE,
MD10804 $MN_EXTERN_M_NO_SET_INT
MD10806 $MN_EXTERN_M_NO_DISABLE_INT,
MD10800 $MN_EXTERN_CHAN_SYNC_M_NO_MIN,
MD10802 $MN_EXTERN_CHAN_SYNC_M_NO_MAX
MD20095 $MC_EXTERN_RIGID_TAPPING_M_NR
MD26008 $MC_NIBBLE_PUNCH_CODE
10810 EXTERN_MEAS_G31_P_SIGNAL EXP, N12 FBFA
- Config. of measuring inputs for G31 P.. BYTE PowerOn
-
- 4 1, 1, 1, 1 0 3 2/2
10814 EXTERN_M_NO_MAC_CYCLE EXP, N12 H2,K1
- Macro call via M function DWORD PowerOn
-
- 30 -1, -1, -1, -1, -1, -1, -1,
-1...
- - 2/2
