Machine data
2.2 General machine data
Parameter Manual
48
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Bits 9-31:
Currently unassigned.
Description: With this MD you define whether tool length offset and tool radius offset are
also to be suppressed with language commands G53, G153 and SUPA
The machine data is bit-coded.
Bit 0 = 0: G53, G153 and SUPA cause block-by-block suppression of work off-
sets. The active tool length offset and tool radius offset remain active.
Bit 0 = 1: G53, G153 and SUPA cause block-by-block suppression of work off-
sets, active tool length offset and tool radius offset. The tool length
behavior can be modified with bit 1.
Bit 1 is only evaluated, if the value of bit 0 is 1.
Bit1 = 0: with bit 0 set, the tool length is always suppressed with G53, G153
and SUPA.
Bit1 = 1: with bit 0 set the tool length is only suppressed with G53, G153
and SUPA, if a cutting edge is not selected in the same block (this can also
be the cutting edge that is already active).
Description: Setting the various bits can influence the processing of the interrupt rou-
tine activated by M96 P...
Bit 0 = 0,
No interrupt program possible, M96/M97 are normal M functions
Bit 0 = 1,
Using M96/M97 to activate an interrupt program is allowed
Bit 1 = 0,
Continue processing part program at the final position of the next block
after the interrupt block
Bit 1 = 1,
Continue processing part program from interrupt position
Bit 2 = 0,
The interrupt signal immediately interrupts the current block and starts the
interrupt routine
Bit 2 = 1,
The interrupt routine will not be started until the end of the block
Bit 3 = 0,
Interrupt machining cycle at an interupt signal
Bit 3 = 1,
Do not start interrupt program until the end of a machining cycle.
10760 G53_TOOLCORR N12 FBFA
- Method of operation of G53, G153 and SUPA DWORD NEW CONF
-
-- 0 0 3 2/2
10808 EXTERN_INTERRUPT_BITS_M96 EXP, N12 FBFA
- Activate interrupt program (ASUB) DWORD PowerOn
-
-- 0 0 - 1/1
