Machine data
2.2 General machine data
Parameter Manual
66
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
The connected handwheels are adapted to the control in MD11320
$MN_HANDWH_IMP_PER_LATCH.
The number of pulses generated by the handwheel for each handwheel detent
position has to be entered. The handwheel pulse weighting must be defined
separately for each connected handwheel (1 to 3). With this adaptation, each
handwheel detent position has the same effect as one press of the traversing
key in incremental traversal.
Entering a negative value reverses the direction of rotation of the hand-
wheel.
Related to:
MD31090 $MA_JOG_INCR_WEIGHT
(weighting of an increment of a machine axis for
INC/manual).
Description: In incremental traversal or handwheel travel, the number of increments to be
traversed by the axis can be defined by the user, e.g. via the machine con-
trol panel.
In addition to the variable increment size (INCvar), 5 fixed increment sizes
(INC...) can also be set.
The increment size for each of these 5 fixed increments is defined collec-
tively for all axes by entering values in JOG_INCR_SIZE_TAB [n]. The default
setting is INC1, INC10, INC100, INC1000 and INC10000.
The entered increment sizes are also active for DRF.
The size of the variable increment is defined in SD41010
$SN_JOG_VAR_INCR_SIZE.
Related to:
MD31090 $MA_JOG_INCR_WEIGHT (weighting of an increment for INC/
manual)
NC/PLC interface signal DB3300 DBX1001.0-4,1005.0-4,1009.0-4
(Geometry axis 1-3 active machine function: INC1; ...;
INC10000)
NC/PLC interface signal DB390x DBX5.0 - .5
(active machine function: INC1; ...; INC10000).
11320 HANDWH_IMP_PER_LATCH N09 H1
- Handwheel pulses per detent position DOUBLE PowerOn
-
- 6 1., 1., 1., 1., 1., 1. - - 2/2
11330 JOG_INCR_SIZE_TAB EXP, N09 H1
- Increment size for INC/handwheel DOUBLE PowerOn
-
- 5 1., 10., 100., 1000.,
10000.
0.0 - 1/1
