Siemens SINUMERIK 808D ADVANCED User Manual

Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
75
Machine data
2.2 General machine data
Description: This machine data is used to adapt the rapid traverse override switch to the
interface coding of the PLC interface.
1: The 5 low-order bits of the PLC interface signal DB3200 DBX5 (Rapid tra-
verse override A-H) are interpreted as a Gray code. The value which is read
corresponds to a switch setting.
It is used as an index for selecting the correct override factor from the
table of MD12050 $MN_OVR_FACTOR_RAPID_TRA[n].
0: The rapid traverse override byte of the PLC interface is interpreted as
a binary representation of the override value in percent (limit 200 percent).
Related to:
NC/PLC interface signal DB3200 DBX5 (Rapid traverse override A-H)
MD12050 $MN_OVR_FACTOR_RAPID_TRA[n]
(Evaluation of the rapid traverse override switch)
Description: Evaluation of the rapid traverse override switch with gray-coded interface.
Not relevant with:
MD12040 $MN_OVR_RAPID_IS_GRAY_CODE = 0
Related to:
NC/PLC interface signal DB3200 DBX5 (Rapid traverse override A-H)
Description: This machine data is used to adapt the spindle speed override switch to the
interface coding of the PLC interface.
1: The 5 low-order bits of the "spindle speed override" PLC interface sig-
nal are interpreted as a Gray code. The value which is read corresponds to a
switch setting. It is used as an index for selecting the correct override
factor from the table of MD12070 $MN_OVR_FACTOR_SPIND_ SPEED [n].
0: The spindle speed override byte of the PLC interface is interpreted as a
binary representation of the override value in percent (limit 200 percent).
Related to:
NC/PLC interface signal DB380x DBX2003 (Spindle speed override)
MD12070 $MN_OVR_FACTOR_SPIND_SPEED[n]
(Evaluation of the spindle speed override switch)
12040 OVR_RAPID_IS_GRAY_CODE EXP, N10 V1,Z1
- Rapid traverse override switch Gray-coded BOOLEAN PowerOn
-
- - TRUE 0 - 1/1
12050 OVR_FACTOR_RAPID_TRA EXP, N10 V1,Z1
- Evaluation of rapid traverse override switch DOUBLE PowerOn
-
- 31 0.00, 0.01, 0.02, 0.04,
0.06, 0.08, 0.10...
0.00 1.00 1/1
12060 OVR_SPIND_IS_GRAY_CODE EXP, N10 V1,Z1
- Spindle override switch Gray-coded BOOLEAN PowerOn
-
- - TRUE 0 - 1/1
