Machine data
2.2 General machine data
Parameter Manual
76 Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
Evaluation of the spindle-specific override switch with Gray-coded interface.
Special function of the 31st value for the velocity control:
The setting of the 31st override value defines the dynamic reserves which
take the velocity control to be an excessive increase in the spindle feed.
The setting should correspond to the highest override factor actually used.
The function of the 31st value is thus identical to the effect of MD12100
$MN_OVR_FACTOR_LIMIT_BIN when using the binary-coded interface.
Not relevant for:
MD12060 $MN_OVR_SPIND_IS_GRAY_CODE = 0
Related to:
NC/PLC interface signal DB380x DBX2003 (Spindle speed override)
Description: The PLC input/output image of the stations with these logical addresses
is not connected to the real I/Os
Description: The PLC input/output image of the stations with these logical addresses
is not connected to the real I/Os
12070 OVR_FACTOR_SPIND_SPEED EXP, N10 V1,Z1
- Evaluation of spindle override switch DOUBLE PowerOn
-
- 31 0.5, 0.55, 0.60, 0.65,
0.70, 0.75, 0.80...
0.00 2.00 1/1
12986 PLC_DEACT_IMAGE_LADDR_IN N10 -
- Deactivation of I/O connection to the PLC image DWORD PowerOn
-
808d-me42 16 0, 9, 18, 27, 36, 96,
112, -1...
-1 255 -1/1
808d-me62 16 0, 9, 18, 27, 36, 96,
112, -1...
-1 255 1/1
808d-te42 16 0, 9, 18, 27, 36, 96,
112, -1...
-1 255 -1/1
808d-te62 16 0, 9, 18, 27, 36, 96,
112, -1...
-1 255 1/1
12987 PLC_DEACT_IMAGE_LADDR_OUT N10 -
- Deactivation of I/O connection to the PLC image DWORD PowerOn
-
808d-me42 16 -1, -1, -1, -1, -1, -1, -1,
-1...
-1 255 -1/1
808d-me62 16 -1, -1, -1, -1, -1, -1, -1,
-1...
-1 255 1/1
808d-te42 16 -1, -1, -1, -1, -1, -1, -1,
-1...
-1 255 -1/1
808d-te62 16 -1, -1, -1, -1, -1, -1, -1,
-1...
-1 255 1/1
