Machine data
2.2 General machine data
Parameter Manual
80
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
Description:
User data is stored in the NCK-PLC interface, and can be read by the PLC user
from the DB20 during the runup.
Description: User data is stored in the NCK-PLC interface and can be evaluated by the PLC
basic system (currently for software PLC 2xx).
Description: Name of the user program called on the basis of a substitution configured by
MD30465 $MA_AXIS_LANG_SUB_MASK.
The user program is called with the path configured by MD15702
$MN_LANG_SUB_PATH.
Description: Path with which the user program set by MD15700 $MN_LANG_SUB_NAME is called
on the basis of a substitution configured by MD30465 $MA_AXIS_LANG_SUB_MASK:
0: /_N_CMA_DIR (default)
1: /_N_CUS_DIR
2: /_N_CST_DIR
Description: Extensions of files which are saved in the binary format in the passive NCKs
file system.
For these files, there are no restrictions regarding the content.
For ASCII content (e.g. TXT and HTM) any line length is possible; this is not
permissible for NC programs (e.g. MPF, SPF and DEF).
Each extension must comprise precisely three uppercase letters.
14514 USER_DATA_FLOAT N03 P3
- User data (FLOAT) DOUBLE PowerOn
-
- 8 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0...
-3.40e38 3.40e38 7/3
14516 USER_DATA_PLC_ALARM N03 A2,P3
- User data (HEX) BYTE PowerOn
-
- 128 0, 0, 0, 0, 0, 0, 0, 0... 0 - 7/3
15700 LANG_SUB_NAME N01 K1
- Name for substitution subroutine STRING PowerOn
-
- - - - 2/2
15702 LANG_SUB_PATH N01 K1
- Call path for substitution subroutine BYTE PowerOn
-
-- 0 0 2 2/2
17000 EXTENSIONS_OF_BIN_FILES EXP -
- Extensions of binary files STRING PowerOn
-
- 20 JPG, GIF, PNG, BMP,
PDF, ICO...
- - 2/2
